7X06A0CUSG Technical Specification
Lenovo ThinkSystem SR650 Server
Part Number: 7X06A0CUSG
Power Supply: 750W
Networking: 10Gb 4-port Base-T LOM
Memory: 16GB
Details: The ThinkSystem SR650 is equipped with an Intel Xeon Gold 5217 processor featuring 8 cores at 3.0GHz, complemented by 16GB of RAM. It supports 8×3.5in SAS/SATA HDDs and includes a RAID 930-8i with 2GB memory for enhanced data protection. The networking capabilities comprise a 10Gb 4-port Base-T LOM and it operates on a 750W power supply, fitting into a 2U rack space.
Processor: Intel Xeon Gold 5217 8C 3.0GHz
Hard Drive: 8×3.5in SAS/SATA HDD
Operating System: No OS
Optical Drive: No Internal Optical Drive
Ports: Three USB 3.0, one USB 2.0
Others: Supports up to 24 DIMM sockets (12 DIMMs per processor) with a maximum of 3TB using 3DS LRDIMMs and DDR4 memory speeds up to 2933MHz. It can accommodate up to 24x 2.5 Inch hot-swap SATA/SAS HDDs or 12x 3.5 Inch hot-swap drives for a total of 120TB. The system also allows for two internal M.2 SSDs (mirroring) and includes one LOM slot for customized LOM options with RJ-45 or SFP+ ports. The XClarity Controller is standard, with optional upgrades available to Advanced or Enterprise versions, and a VGA Matrox G200 is also available for graphics processing. Additionally, there is an option for dual GPU support.
Network Interface: The onboard LOM slot supports up to 4x 1/10 Gb Ethernet ports, with options for RJ-45 and SFP+ connections, and a dedicated systems management port.
