463-3980 Dell PowerEdge R630 1U Rack Server – High Performance

463-3980 Technical Specifications

Dell PowerEdge R630 1U Rack Server

GENERAL INFORMATION:

• Manufacturer: Dell
• Manufacturer Part Number: 463-3980
• Product Name: PowerEdge R630 1U Rack Mount Server

PROCESSOR & CHIPSET:

• CPU: Intel Xeon E5-2620V3 at 2.4GHz
• Max Turbo Speed: 3.2 GHz
• Number of Cores: 6-Core
• Installed CPU Quantity: 1
• Max CPU Quantity: 2
• Main Processor Features: Hyper-Threading, Intel Turbo Boost Technology 2
• CPU Socket: LGA2011-V3
• Chipset Type: Intel C610

CACHE MEMORY:

• Installed Size: 15 MB L3 Cache
• Cache Per Processor: 15 MB

MEMORY:

• Installed Size: 8 GB (up to 768 GB max)
• Memory Technology: DDR4 SDRAM – ECC
• Memory Speed: 1866 MHz
• Compliance: PC4-17000
• Form Factor: DIMM 288-PIN
• Features: Registered, Dual Rank
• Configuration: 1 x 8 GB
• RAM Slots: 24 x DDR4 RAM Slots
• Supported RAM: 768 GB Load-Reduced ECC, 384 GB Registered ECC
