C1-C4507R+E Technical Specifications
Cisco ONE Catalyst 4500 Series Platform – Cisco ONE Catalyst 4500E 7-Slot Chassis (48Gbps/slot, Fan, No PS)
Slots Available
Free Quantity: 7
Total Quantity: 7
Type: Expansion Slot
Networking Features
Form Factor: Rack-Mountable
Subcategory: Network Hubs and Switches
Type: Switch
Miscellaneous Details
Color Category: Gray
Compliant Standards: ACA TS001, AS/NZ 3548 Class A, AS/NZS 3260, CISPR 22 Class A, CS-03, CSA 22.2 No. 60950, EN 60950, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN50082-1, EN55022, EN55022 Class A, EN55024, FCC CFR47 Part 15, FCC Class A certified, FCC Part 68, ICES-003 Class A, IEC 60950, JATE, NEBS Level 3, UL 60950, VCCI Class A
Height (Rack Units): 11
MTBF: 248,630 hours
Rack Mounting Kit: Included
Environmental Parameters
Humidity Range Operating: 10 – 90% (non-condensing)
Max Operating Temperature: 104 °F
Max Storage Temperature: 167 °F
Min Operating Temperature: 32 °F
Min Storage Temperature: -40 °F
Header Information
Brand: Cisco
Compatibility: PC
Manufacturer: CISCO DS HARDWARE DIRECT
Model: C4507R
Packaged Quantity: 1
Product Line: Cisco ONE Catalyst
Product Type: Switch Chassis
Power Device Specifications
Hot-Plug: Yes
Installed Quantity: 0
Max Supported Quantity: 2
Power Redundancy: Optional
Power Redundancy Scheme: 1+1 (with optional power supply)
Type: Internal Power Supply
Dimensions and Weight
Depth: 12.5 in
Height: 19.2 in
Weight: 44.53 lbs
Width: 17.3 in
Service & Support
Type: Limited Lifetime Warranty
Chassis Information
Installed Device Modules Quantity: 0
Supported Device Modules Quantity: 7
