C9300-24S-E Cisco Catalyst 9300 24-Port SFP Ethernet Switch

C9300-24S-E Technical Specifications

Cisco Catalyst 9300 24-Port 1G SFP Switch

Brand: Cisco Catalyst
Ports: 24x 1G SFP
Uplink Configuration: Modular Uplinks
Default AC Power Supply: 715W AC
Cisco StackWise-480 Support: Yes
Switching Capacity: 208 Gbps
Stacking Bandwidth: 688 Gbps
Cisco StackPower Support: Yes
QoS Scale Entries: 5120
ACL Scale Entries: 5120
DRAM: 8 GB
Flash Memory: 16 GB
VLAN IDs Supported: 4094
Total Switched Virtual Interfaces (SVIs): 1000
Maximum Jumbo Frames: 9198 bytes
Layer: 3
Rack: Rack mountable
The Catalyst 9300 Series is Cisco’s leading stackable enterprise switching platform, engineered for security, IoT, mobility, and cloud applications. It forms the essential building block for Software-Defined Access (SD-Access), Cisco’s primary enterprise architecture. With 480 Gbps, it boasts the industry’s highest-density stacking bandwidth and flexible uplink architecture, making it future-ready with its x86 CPU architecture and increased memory.
