FTLD10CE3C TX/RX Optical Fiber Transceiver 120Gbps

FTLD10CE3C Technical Specifications

TX/RX Optical Fiber 120Gbps

This 12-channel full-duplex transceiver module is designed for high-performance networking applications. It features a hot-pluggable CXP form factor and supports multirate capabilities ranging from 1Gb/s to 11.3Gb/s per channel for 10 Gigabit Ethernet. The maximum link length achievable is 100 meters on OM3 Multimode Fiber (MMF). It operates with an unretimed CPPI electrical interface and requires only a 3.3V power supply, ensuring compatibility with various systems. The module boasts low power consumption at less than 3.5W and utilizes reliable VCSEL array technology for optimal performance. Additionally, it includes digital diagnostics that allow for monitoring of both Tx and Rx optical power. The commercial operating temperature range is from 0ºC to 70ºC, making it suitable for diverse environments.
