ONENTWK-EN-07-10, Cisco ONE Catalyst 4500 Series Switch Platform

ONENTWK-EN-07-10 Technical Specifications

Cisco ONE Catalyst 4500 Series Platform

Product Line: Cisco ONE Catalyst
Product Series: C4500
Product Type: Managed Switch Chassis
Device Type: 192-port Switch with 2x SUP8e and 4x 4748-UPoE
Enclosure Type: Rack-mountable 11U
Subtype: Gigabit Ethernet
Ports: 192 x 10/100/1000 (PoE) + 16 x SFP+
Power Over Ethernet (PoE): PoE+
Performance: Switching capacity of 928 Gbps, per-slot capacity of 48 Gbps, IPv6 routing at 125 Mbps, and IPv4 routing at 250 Mbps.
Capacity: QoS hardware entries: 128,000; Security services entries: 128,000; VLANs: 4,094; ARP entries: 47,000; IPv6 routing table entries: 128,000; IPv4 routing table entries: 256,000; Spanning Tree Protocol instances: 10,000; Switched virtual interfaces (SVIs): 4,094; NetFlow entries: 128,000.
MAC Address Table Size: 55K entries
Routing Protocol: PIM-SM, PIM-DM, PIM-SSM
Remote Management Protocol: RMON 1, RMON 2, CLI.
