SF110D-08-AR Cisco Small Business 8-Port Switch

SF110D-08-AR Technical Specifications

Cisco Small Business SF110D-08 Unmanaged 8-Port Switch

Interface
Connector Type: RJ-45
Quantity: 8
Type: 100Base-TX
Networking Features
Standards Compliance: IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features: Auto-uplink (auto MDI/MDI-X), Cable test, Energy Efficient Ethernet, Fanless design, Quality of Service (QoS), Security lock slot (cable lock sold separately), Weighted Round Robin (WRR) queuing
Form Factor: Desktop, Wall-mountable
Jumbo Frame Support: 9216 bytes
Manageability: Unmanaged
Status Indicators: Link/activity, System
Subcategory: Network hubs and switches
Subtype: Fast Ethernet
Miscellaneous
Color: Black
Compliance: CSA 22.2, FCC CFR47 Part 15, UL 60950
Environmental Parameters
Operating Humidity: 10 – 90% (non-condensing)
Storage Humidity: 5 – 90% (non-condensing)
Max Operating Temperature: 104 °F
Max Storage Temperature: 158 °F
Min Operating Temperature: 32 °F
Min Storage Temperature: -4 °F
Header
Brand: Cisco
Compatibility: PC
Manufacturer: CISCO DS HARDWARE DIRECT
Model: SF110D-08
Packaged Quantity: 1
Product Series: SF110
Product Line: Cisco Small Business
Power Device
Current Required: 500 mA (operating)
Nominal Voltage: DC 12 V
Type: External power adapter
Capacity
Type: QoS hardware queues
Value: 4
Dimensions & Weight
Depth: 5.1 in
Height: 1.1 in
Weight: 13.4 oz
Width: 5.1 in
Flash Memory
Installed Size: 128 MB
Performance
Forwarding Performance: 1.4 Mpps (64-byte packet size)
Switching Capacity: 1.6 Gbps
Ports
Quantity: 8
Type: 10/100
RAM
Installed Size: 128 MB
