C9500-48X-A Cisco Catalyst 9500 48-Port Network Advantage Bundle

C9500-48X-A Technical Specifications

Catalyst 9500 48-port 10G bundle, Network Advantage

Capacity
Type: FNF entries
Value: 512,000
Type: Host IPv4 routes
Value: 32,000
Type: Host IPv6 routes
Value: 16,000
Type: Indirect IPv4 routes
Value: 64,000
Type: Indirect IPv6 routes
Type: Multicast scale
Value: 48,000
Type: QoS ACL scale
Value: 18,000
Type: Security ACL scale
Type: Switched virtual interfaces (SVIs)
Type: VLAN IDs
Value: 4,000
Dimensions & Weight
Depth: 21.5 in
Height: 1.7 in
Weight: 25.75 lbs
Width: 17.5 in
Environmental Parameters
Operating Humidity Range: 5 – 90% (non-condensing)
Storage Humidity Range: 5 – 95% (non-condensing)
Max Operating Temperature: 104 °F
Max Storage Temperature: 149 °F
Min Operating Temperature: 32 °F
Min Storage Temperature: -4 °F
Flash Memory
Installed Size: 16 GB
Header
Brand: Cisco
Bundled with: Cisco Catalyst 9500 8 x 10GE Network Module (C9500-NM-8X)
Edition: Network Advantage
Kit: Bundle
Manufacturer: CISCO DS HARDWARE DIRECT
Model: 9500
Packaged Quantity: 1
Product Line: Cisco Catalyst
Interface Provided
Connector Type: SFP+
Qty: 48 SFP+
Type: 10GBase-X
Miscellaneous
Color Category: Gray
Compliant Standards: AS/NZS 60950-1, AS/NZS CISPR22:2004 Class A, CAN/CSA-C22.2 No. 60950-1, CISPR 22 Class A, CISPR 24, CNS 13438 Class A, EN 300 386, EN 55022 Class A, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN50082-1, EN55024, FCC CFR47 Part 15 A, GB 4943, ICES-003 Class A, IEC 60950-1, KN 61000-4, KN22 Class A, KN24, UL 60950-1, VCCI Class A
Encryption Algorithm: 256-bit AES
Height (Rack Units): 1
MTBF: 180,640 hours
Networking
Advanced Switching: Layer 3
Compliant Standards: IEEE 802.1ae, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3x, IEEE 802.3z
Features: 802.1x authentication, Cisco StackWise Virtual, Class-Based Weighted Fair Queuing (CBWFQ), CoAP support, Control plane protection (CoPP), Ethernet over MPLS (EoMPLS), First Hop Security (FHS), Flexible NetFlow (FNF), Hierarchical Virtual Private LAN Service (H-VPLS), IPv6 support, Layer 3 VPN (L3VPN) support, MACsec support, Management Information Base (MIB), MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, NAT support, Non-Stop Routing (NSR), Private VLAN, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Remote Switch Port Analyzer (RSPAN), Secure boot, Spanning Tree Protocol (STP) support, Stateful switchover (SSO), Switched Port Analyzer (SPAN), Virtual Routing and Forwarding (VRF), VLAN Double Tagging (Q-in-Q), Weighted Random Early Detection (WRED), Zero-touch provisioning (ZTP)
Form Factor: Rack-mountable
Jumbo Frame Support: 9198 bytes
MAC Address Table Size: 64K entries
Manageable: Yes
Ports Qty: 48
Remote Management Protocol: NETCONF, RESTCONF, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3
Routing Protocol: BGP, EIGRP, HSRP, IGMP, IS-IS, MSDP, OSPF, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP-1, RIP-2, RIPng, VRRP
Stackable: Stackable
Status Indicators: Status
Subcategory: Network hubs and switches
Subtype: 10 Gigabit Ethernet
Type: Switch
Performance
Type: Forwarding rate
Value: 720 Mpps
Type: Switching capacity (full duplex)
Value: 480 Gbps
Ports
Qty: 48
Type: 10 Gigabit SFP+
Power Device
Features: Front-to-rear airflow
Frequency Required: 50 – 60 Hz
Hot-Plug: Hot-plug
Installed Qty: 2
Max Supported Qty: 2
Nominal Voltage: AC 120/230 V
Power Provided: 950 Watt
Power Redundancy: Optional
Power Redundancy Scheme: 1+1
Type: Internal power supply
Processor
Clock Speed: 2.4 GHz
Installed Qty: 1
RAM
Installed Size: 16 GB
Slot Provided
Free Qty: 0
Total Qty: 1
Type: Expansion slot
Software
Type: Cisco IOS Universal, Cisco ONE Advantage High Term
